PRODUCTS

Commercial Door & Window Hardware

Multi-points Lock Exit Device, CMP500 Series

The CMP500 Series is an advanced fire-rated, multi-point locking system meticulously engineered to deliver maximum security and durability for high-traffic environments. This innovative multi-point lock exit device is certified to meet rigorous standards, including EN1125, EN1634, and EN12211 6000Pa, ensuring exceptional performance and reliability in critical situations. Its robust construction guarantees that it can withstand significant force, making it an ideal choice for facilities requiring enhanced protection. Additionally, the CMP500 Series offers a variety of finish options, allowing for customization to match diverse architectural styles while maintaining aesthetic appeal. This combination of safety, durability, and design versatility makes it a premier choice for any application.checklist_mark_icon-15px

Request An Inquiry

CE certification     fire certification

SPECIFICATION

  • Feature

    Pullman latch, lateral latch modular design, optional

  • Hand

    Non-handed

  • Certificate, CE marks

    EN1125

    EN1634-1

    EN12211, 6000Pa: CMP511 certificate

  • Material

    Stainless steel

    Steel

  • Finish

    Standard: Stainless steel satin, Silver painted

    Optional: Polishing, PVD, Black, Red

  • Lock point

    CMP501: 1 lock point

    CMP505: 1 lock point

    CMP506: 2 lock points

    CMP507: 2 lock points

    CMP508: 3 lock points

    CMP509: 4 lock points

    CMP510: 3 lock points

    CMP511: 4 lock points

  • Device for door width

    Standard 960mm (push bar 850mm)

    Extend length 1210mm (push bar 1100mm)

  • Device for door height

    Standard rods accommodate 2300mm

    Extension rods for 2440mm doors

    Special rods for 3048mm doors

  • Fasteners & sex bolts

    Screw pack for 44mm to 57mm thick metal or wood doors

  • Trim lock tumbler

    Square shape  Hexadecagon_figure_icon

  • Dogging, not fire-rated

    Not available

  • Trim

    CMPA004B, 104, 008, 010, 012, 112, 212
