Multi-points Lock Panic Exit Device, CMP600 Series
The CMP600 Series is engineered to provide enhanced security through its innovative design featuring multiple locking points. This multi-point lock panic exit device is specifically crafted to meet the highest safety demands in various environments, including commercial and industrial settings. With its robust construction, the CMP600 Series ensures that doors remain securely fastened, significantly reducing the risk of unauthorized entry. Additionally, these devices comply with stringent ANSI, BHMA, and UL standards, as well as relevant fire ratings, guaranteeing reliable protection during emergencies. The combination of advanced security features and adherence to safety regulations makes the CMP600 Series an excellent choice for safeguarding any facility.
SPECIFICATION
-
- Feature
-
Pullman latch, lateral latch modular design
The mortise lock must comply with EN1125.
-
- Hand
-
Non-handed
-
- Compliance
-
ANSI/BHMA A156.3 grade 1
UL10C, fire rated
EN1125
EN1634-1, fire rated
-
- Material
-
Stainless steel
Steel
-
- Finish
-
Standard: Stainless steel satin, Silver painted
Optional: Polishing, PVD, Black, Red
-
- Lock point
-
CMP601: 1 lock point
CMP605: 1 lock point
CMP606: 2 lock points
CMP607: 2 lock points
CMP608: 3 lock points
CMP609: 4 lock points
CMP610: 3 lock points
CMP611: 4 lock points
-
- Touch bar
-
Half length of device
-
- Device for door width
-
24: 24" (610 mm)
36: 28" to 36" (711mm to 914 mm)
48: 34" to 48" (864 mm to 1219 mm)
-
- Device for door height
-
Standard rods accommodate 86" (2200mm)
Extension rods for 96" (2438mm)
Special rods for 120" (3048mm)
-
- Fasteners & sex bolts
-
Screw pack for 1 3/4" (44mm) to 2 1/4" (57mm) thick metal or wood doors
-
- Trim lock tumbler
-
CMP605: Square shape
CMP601, 606, 607, 608, 609, 610, 611: Cross shape
-
- Dogging, not fire-rated
-
Hex key
-
- Trim
-
CMPA004, 104, 008, 010, 012, 112, 212
