CE & UL Listed Panic Touch Bar, CMP400 Series
The CMP400 Series is expertly crafted to provide an impressive selection of finishes and materials, effectively merging style with functionality to enhance any environment. This panic touch bar is designed to meet rigorous standards, including ANSI, BHMA, UL, and CE, ensuring that each panic touch bar delivers exceptional reliability and performance in critical situations. Not only does the CMP400 Series prioritize safety, but it also incorporates aesthetic appeal, allowing it to blend seamlessly into various architectural designs. This combination of robust engineering and elegant design makes the CMP400 Series an ideal choice for both commercial and residential spaces, ensuring peace of mind without sacrificing style.
SPECIFICATION FOR UL CERTIFICATION
-
- Hand
-
Non-handed
-
- Certificate
-
ANSI/BHMA A156.3 grade 1
UL10C, fire rated
-
- Material
-
Stainless steel
Steel
-
- Finish
-
Standard: Stainless steel satin, Silver painted
Optional: Polishing, PVD, Black, Red
-
- Lock point
-
CMP401: 1 lock point
CMP406: 2 lock points
CMP436: 2 lock points
CMP402: 1 lock point
CMP407: 2 lock points
-
- Touch bar
-
CMP401, 406, 436: Half length of device
CMP401, 407: Full length of device
-
- Device for door width
-
24: 24" (610 mm)
36: 28" to 36" (711mm to 914 mm)
48: 34" to 48" (864 mm to 1219 mm)
-
- Device for door height
-
Standard rods accommodate 84" (2134mm)
Extension rods for 96" (2438mm)
Special rods for 120" (3048mm)
-
- Fasteners & sex bolts
-
Screw pack for 1 3/4" (44mm) to 2 1/4" (57mm) thick metal or wood doors
-
- Trim lock tumbler
-
Cross shape
-
- Dogging, not fire-rated
-
Hex key dogging
-
- Trim
-
CMPA004, 104, 401, 410, 420, 801
SPECIFICATION FOR CE CERTIFICATION
-
- Hand
-
Non-handed
-
- Certificate
-
EN1125
EN1634-1, wooden door 90 minutes and steel door 120 minutes
-
- Material
-
Stainless steel
Steel
-
- Finish
-
Standard: Stainless steel satin, Silver painted
Optional: Polishing, PVD, Black, Red
-
- Lock point
-
CMP401: 1 lock point
CMP406: 2 lock points
CMP436: 2 lock points
CMP402: 1 lock point
CMP407: 2 lock points
-
- Touch bar
-
CMP401, 406, 436: Half length of device
CMP401, 407: Full length of device
-
- Device for door width
-
24: 24" (610 mm)
36: 28" to 36" (711mm to 914 mm)
48: 34" to 48" (864 mm to 1219 mm)
-
- Device for door height
-
Standard rods accommodate 7' (2134mm)
Extension rods for 96" (2438mm)
Special rods for 120" (3048mm)
-
- Fasteners & sex bolts
-
Screw pack for 1 3/4" (44mm) to 2 1/4" (57mm) thick metal or wood doors
-
- Trim lock tumbler
-
Cross shape
CMP436 is square shape
-
- Dogging, not fire-rated
-
Hex key
-
- Trim
-
CMPA004, 014, 104, 008, 010, 012, 112, 212, 801
