Narrow Stile Panic Exit Device, CMP750 Series
The CMP750 Series is thoughtfully designed to complement any architectural style, available in an array of finishes and materials that cater to diverse design preferences. These narrow stile panic exit devices are not only aesthetically pleasing but also engineered to meet stringent ANSI, BHMA, and UL standards, ensuring top-tier safety and reliability. Their robust construction guarantees dependable performance in emergency situations, providing peace of mind for building occupants. By seamlessly integrating safety features with sophisticated design elements, the CMP750 Series offers a perfect balance of functionality and style, making it an excellent choice for both commercial and residential applications.
SPECIFICATION
-
- Feature
-
Modular design, more than 4 point locks are available.
Security anti-thrust latch
-
- Hand
-
Non-handed
-
- Compliance
-
ANSI/BHMA A156.3 grade 1
UL10C, 3-hour fire rated
-
- Material
-
Stainless steel
Steel
Aluminum
-
- Finish
-
Standard: Stainless steel satin, Silver painted
Optional: Polishing, PVD, Black, Red
-
- Lock point
-
CMP751: 1 lock point
CMP753: 1 lock point
CMP755: 1 lock point
CMP756: 2 lock points
CMP757: 2 lock points
CMP758: 3 lock points
CMP759: 4 lock points
CMP760: 3 lock points
CMP761: 4 lock points
-
- Touch bar
-
Half length of device
-
- Device for door width
-
24: 24" (610 mm)
36: 28" to 36" (711mm to 914 mm)
48: 34" to 48" (864 mm to 1219 mm)
-
- Device for door height
-
Standard rods accommodate 84" (2134mm)
Extension rods for 96" (2438mm)
Special rods for 120" (3048mm)
-
- Fasteners & sex bolts
-
Screw pack for 1 3/4" (44mm) to 2 1/4" (57mm) thick metal or wood doors
-
- Trim lock tumbler
-
Cross shape
Square shape for CMP755
-
- Dogging, not fire-rated
-
Hex key dogging, cylinder dogging
-
- Trim
-
CMPA401, 420, 750
-
- Minimum door thickness
-
44mm
