3D Stainless Steel Adjustable Concealed Hinge, CHS300
The CHS300 adjustable concealed hinge is expertly crafted from stainless steel 304, ensuring exceptional durability and resistance to corrosion. Designed for versatility, this hinge is suitable for wood, casting, steel and aluminum frames, accommodating various door types including wood doors, steel doors, profile doors and folder doors. Its non-handed configuration simplifies installation, allowing for easy adaptability in diverse applications. The adjustable feature provides precise alignment and smooth operation, enhancing the functionality of any door. Ideal for both residential and commercial settings, the CHS300 is a reliable choice for professionals seeking quality and flexibility in their door hardware solutions.
SPECIFICATION
-
- Application
-
Wood frames
Casting frames
Steel frames
Aluminum frames
-
- Door
-
Wood door
Steel door
Profile door
Folding door
-
- Material
-
Stainless steel 304
-
- Load capacity
-
300kg
-
- Standard
-
EN1935:2016
-
- Length
-
240mm
-
- Minimum door thickness
-
Not less than 45mm
-
- Opening angle
-
Up to 180 degrees
-
- Continuously adjustable in 3-Dimensions
-
Side: +/- 3mm
Height: +/- 3mm
Depth: +/- 1mm
-
- Hand
-
Non-handed
-
- Finish
-
SS
PS
AB
PVD
-
- Quantity for single door
-
2pcs
-
- Feature
-
The 3rd hinge will increase loading capacity by 20%. Please refer to the instructions.
