Deadbolt Lock, CML816D

Moritse Locks　

The CML816D is a high-performance deadbolt lock engineered to provide secure access with ease. Featuring a robust deadbolt, it can be operated by a key from both the inside and outside, offering flexibility and convenience when locking or unlocking the door. This versatile lock is designed for a wide range of door applications, from residential to commercial settings, ensuring superior security and reliable performance. With its user-friendly operation and durable construction, the CML816D enhances safety without compromising ease of use. Ideal for spaces where access control and security are paramount, this lock delivers both functionality and peace of mind.checklist_mark_icon-15px

Request An Inquiry

BHMA     ul-certification     fire certification

SPECIFICATION

  • Certificate (Pending)

    ANSI/BHMAA156.13, Grade 1

    UL10C, 3-hour fire rated

  • Material

    Stainless steel

  • Finish

    SSS

    AB

    PVD

  • ANSI Function

    F01, F04, F05, F07, F09, F13, F14, F16, F17, F18, F19, F20, F22, F29 and more

Application:
CML800 Series locks are ideal for use in office building, airport, schools, hospitals and factories，

where the finest hardware must also deliver consistent, dependable operation and stand up to

constant use and abuse.


Specification:
◎Universal lock case – many functions in one case
◎Field-reversible handing without opening lock case
◎Locking thumbturn on the inside of door visually shows when the door is locked and unlocked
◎Independent lever rotation
◎Certificate to ANSI/BHMA A156.13-2005, Grade 1
◎Certificate to UL 3 hours fire rated
◎Lockcase: Heavy gauge steel, with zinc dichromate finish for corrosion resistance.
◎Deadbolt: One-piece stainless steel, 25mm throw.
◎Latchbolt: Stainless steel, 2 piece mechanical with anti-friction insert. 19mm throw.
◎Auxiliary Latchbolt: stainless steel
◎Strike: stainless steel, ANSI straight lip standard, 4-7/8" (124mm) x 1-1/4" (32mm).
◎Door Thickness: 1-3/4" (45mm) standard. Optional 1-3/8"(35mm), 2-1/2"(64mm)
◎Backset: 2-3/4" (70mm) Certificate Certificate



Function:

F16, F17, F18, F29
